SharePoint/ProjectServer 2016
Beta 2 version is available to explore now, and in this blog post I will walk
through installation steps to help users follow and setup an on-premises
SharePoint server 2016 farm.
Note that Project Server service application is now included within a same set of setup files. We don't have to install separate setup files for Project Server, you will find Project Server Service application to choose to configure as part of farm configuration step.
During the installation process,
I will highlight any new/additional steps or installation screens specific to
SharePoint 2016. Also note that this installation is carried using Beta 2
version, that is 99% feature complete as Microsoft has quoted and must be very
identical to the RTM version coming next year.
For testing purposes, I am
preparing a single server farm and I have a separate database server that is
running SQL Server 2016 CTP 3.0.
Exactly like SharePoint 2013,
lets start with installation of prerequisites.
Pre-requisites options:
SharePoint server expects certain pre-requisites to be
installed prior to actual SharePoint installation. Below are our option to prepare
SharePoint server with pre-requisites:
- Online installation, using
Pre-requisite tool (recommended)
- Manual installation of
pre-requisites by downloading required setups files.
For offline installation (option-2), you can download below
required pre- requisites and install on server. Please always refer to this
MSDN
to check for any changes in pre-requisites and their respective download links:
·
Web Server (IIS) role
·
Application Server role
·
Microsoft .NET
Framework version 4.5.2
·
Microsoft SQL Server
2012 Native Client
·
Microsoft WCF Data
Services 5.6
·
Microsoft Information
Protection and Control Client (MSIPC)
·
Microsoft Sync
Framework Runtime v1.0 SP1 (x64)
·
Windows Server
AppFabric 1.1
·
Cumulative Update
Package 7 for Microsoft AppFabric 1.1 for Windows Server (KB 3092423)
·
Microsoft ODBC Driver
11 for SQL Server
·
Update for Microsoft
.NET Framework to disable RC4 in Transport Layer Security (KB2898850)
·
Visual C++
Redistributable Package for Visual Studio 2012
·
Visual C++
Redistributable Package for Visual Studio 2015
In this blog post, I am using pre-requisite tool that comes
with SharePoint setup to configure my server.
Installing Pre-requisites
Run setup as administrator, and choose install software
pre-requisites.
1.
2.
3.
4.
5. After restart, the
pre-requisite tool will resume with remaining installation.
6. Summary screen will show status as below:
At the end of installation, go through the completion status
screen as above to identify if any pre-requisite got failed while installation
Installing SharePoint Server 2016:
Choose Install SharePoint server from setup dialog, and
follow the screen shots to complete the installation process.
1.
2 2. Accept the agreement check-box, and continue:
3. Choose a file location, if
it’s different then the default location mentioned:
4.
5. At the end of installation of setup binaries, run the configuration wizard
to complete the configuration and create farm:
6.
7. Choose create a new server farm to create a new SharePoint 2016
far. Connection to an existing farm option can be used to join new server to an
existing farm.
8. Define the required
configuration fields below and proceed:
9 9. Pass-phrase is important, so
define and save it somewhere to refer later if required. As it would be
required to add another server to scale up your existing farm.
10. Below screen is part of new
enhancements/change to SharePoint 2016 deployment process. This will let you
choose your server role within a farm, earlier it was all about manually
setting up a required application services based on server role in a farm.
11. And the final configuration dialog box let you choose port number for your
Central Admin site:
12. Configuration summary page:
13. Below step may take a while
to complete:
14. At the end of successful
configuration, you will be presented with summary configuration. Click finish
to launch Central Administration website:
15. Once Central
Administration site launched, you can choose wizard to configure services
16. Another change to
SharePoint 2016 deployment process is that Project Server is now part of same
SharePoint installation as service application.
Project Server always was an application
service in SharePoint, but previous versions requires separate set of setup
files to be installed to enable Project Server application service in existing
SharePoint farm.
17. And here you have a shiny new
SharePoint Server 2016 farm ready for you to explore J
More to come soon, keep visiting my blog.
